250 psi pump quiet operation 35Db solenoid valve – Controls flow of water in the pump in built filter – helps protect your misting nozzles built in water by pass self-priming
Nickel-plated brass button series With stainless-steel Orifice Standard 10/24-inch thread 0. 012-inch Orifice Rust-resistant fixed impeller pin 0. 014 GPM Flow per Nozzle
Maximum inlet pressure: 100 psi Minimum inlet pressure: self- priming. Maximum outlet pressure: 250 psi (depends on line length and numbers of nozzles) maximum flow: 0. 9 GPM full load Amps. 110V AC: 0. 7 amps 12V DC: 4. 0 amps Voltage: 110V-220V AC/ 12V DC (refer manufacturing label on the pump) noise level: 40 dB. Maximum fluid temperature: for room temperature/ cold water applications only
Max pressure 250 psi Available in 110 V, 220 V & 12 VDC Durable Rust Proof Enclosure Thermal Safety Switch Oil-less Pumps may generate heat, motor manufacturer have installed built-in thermal safety switch to improve the longevity of pumps Standard pump inlet: 3/8-inch push lock Fitting. Standard Pump outlet: ¼ inch Push-lock fitting. Max pressure 250 psi 110 V AC
1. Solenoid Valve Solenoid valve controls the flow of the water in to the pump. You may leave the inlet water source on at all the time. Water will enter the pump only when main power switch is turned on. Likewise, water flow will be cut off when power switch is turned off. No adjustment is ever required for solenoid valve.
